50hp

Engine

Model: SL4100

Type: 4 CYLINDER VERTICAL ,WATER COOLED 4 STROKE

Rated power(KW):37KW,50 HP

Rated rotation speed(r/min): 2300 rpm

Drive System

Clutch: Single-function dry constant meshing

Gear Box:4x（2+1)

Main Drive: One Pair of Spiral Bevel Gearing

Traveling Mechanism

Front Tyre:8.3-20

Rear Tyre:12.4-28

Steering Gear: Hydraulic Steering

Brake: Oil Immerszd Multiplate Disc

Working Device

Hydraulic System

Lifting Capacity at 610mm Behind Lift Point(N):9100

3-Point Suspension:Category:II

P.T.O Rotating Speed (rpm): 540/720 or 540/1000

Tractor Parameters

Wheel base(mm): 2073

Front wheel tread/Rear wheel tread(mm): 1300/1315-1615

Rated tractive force(N): 14200

Overall dimensions

LXWXH (mm): 4010/3997x1640x1645
