90hp

Type

4WD Wheeled Type

Length（including after the flag）

3700

Width

2100mm

Height （up to the top silencer）

2700mm

Rear Wheel Tread

1520mm

Axle Base

2316mm

Min. Ground Clearance

350mm

Structure weight

2940kgs

Rated traction force

1520kgs

Engine Model

YTO 4MCT65A

Engine Type

4-Cylinder

Cooler type

Water

Stroke

4 Stroke

Rated Power

66.2kw

Rated Speed

2300RPM

Maximum torque/speed(N.m(r/min)

380+/-5%/1500-1700

Mini speed

750+/-30

Fuel

Diesel

Front Tire Tyre

11.2-24

Rear Tire Tyre

16.9-34

Clutch

Dual-stage clutch

Steering

Power steering

Transmission Type

(8+2)×2 with creeper shift

Suspension Type

3-point links

Type and Rev

Semi-independent Type 540/1000

Spline Size

F35 Rectangle Spline with 8 teeth
