ZL50F

Engine Details

Model

Weichai sitaierWD61567G3-29 or as customer’s requirements

Engine type

In-line arrangement, water-cooled, four-cycle diesel Engine

Rated Power

162 KW

Rated Speed

2200 r/min

Min.ful consumption

214 g/kw.h

Bucket

Bucket Capacity

3.0 m3

Bucket type

Heavy-duty bolt on teeth

Rated Loading weight

5000 kg

Total Weight

16000 kg

Overall Dimensions

Overall Length

7836 mm

Overall Height

3300 mm

Overall Width

3010 mm

Max. discharge height

3100 mm

Wheel base

3200 mm

Tread

2250 mm

Operating Specifications

Steering System

Articulated Frame with hydraulic power steering

Min Turning Radius

7268 mm

Driving System

Hydraulic converter

Brake System

Service Brake

Four Wheel Hydraulic spread-shoed brake

Parking Brake

Hand operated

Tyre

23.5-25
